nuestros productos
Suministros para la Industria Petrolera
Calidad y Respaldo
Nuestros Productos
Nuestros productos han sido probados y utilizados alrededor del mundo mostrando resultados muy sobresalientes en diferentes tipos de aplicaciones con restricciones y especificaciones distintas. Trabajando con nosotros ahorrará tiempo y dinero, nuestros clientes lo garantizan. Somos representantes exclusivos de reaming shoes, centralizers, y float equipment. Proveemos productos con toda la calidad y respaldo propio de nuestros aliados.
Reaming Shoes, Centralizers, Float Equipment
![](https://oilandgassupplier.com/wp-content/uploads/2022/10/products-varel.png)
PDC Direction Drill Bits
The Pred-O-Tor reamer shoe has been designed to be an uncompromising solution to today’s most challenging wellbore conditions. The nose has an innovative profile design to aid in getting casing to T.D. by overcoming wellbore restrictions, but also includes integral hardfaced blades and optimized jetting, to ream and clean out the hole as the casing is run. The addition of PDC cutters on the outer shoulder of the Pred‑O‑Tor allows the shoe to efficiently ream and open the hole, where formation issues have impacted string progressing. The blades have tungsten carbide buttons to further assist with hole cleaning.
Features:
- Innovative nose profile.
- Hardfaced blades.
- PDC to aid reaming.
- Efficient drillout.
- Aggressive right-hand blades.
- Casing friendly carbide gauge buttons.
- One-piece milled steel body.
Casing Solutions
![](https://oilandgassupplier.com/wp-content/uploads/2022/10/FloatEquipment.png)
Float
Equipment
Differentiated full range of float equipment and cementing tools used in running casing, liner, or screen applications.
![](https://oilandgassupplier.com/wp-content/uploads/2022/10/Centralizers_Angle.png)
Bow Spring Centralizers
A complete offering of bow spring centralizers to help get casing, liners, or screens to bottom with ease in demanding applications.
![](https://oilandgassupplier.com/wp-content/uploads/2022/10/SolidBodyCentrializers.png)
Solid Body Centralizers
A complete offering of solid body centralizers to help get casing, liners, or screens to bottom with ease in demanding applications
Deployment Enhancement
![](https://oilandgassupplier.com/wp-content/uploads/2022/11/ReamingShoes.png)
Reaming Shoes
A proprietary range of reamer shoes have been specifically designed for various applications to aid in the installation of casing, liner, or screen.
![](https://oilandgassupplier.com/wp-content/uploads/2022/11/CasingShoes.png)
Casing Shoes
Guide shoe technology to aid with the running of any casing, liner, and screen applications.
![](https://oilandgassupplier.com/wp-content/uploads/2022/11/CasingDrilling.png)
Casing Drilling
A unique set of casing drilling technologies to enable effective milling and torque reduction requirements
Range and Application
![](https://oilandgassupplier.com/wp-content/uploads/2022/10/products-matrix.png)
Range and Application
- High strength, low friction centralizer.
- Cemented casing and liners.
- Well screens, slotted liners, run with swell packers.
- Max operating temp: 437°F/225°C.
- Sizes: 4.1/2” to 7” (Various ODs).
- Extremely high Impact strength, low friction centralizer.
- Designed for Arctic operations.
- Ideally suited for large Intermediate Casing Strings where impact from surface operations are a concern.
- Max operating temp: 437°F/225°C.
- Sizes: 4.1/2” to 10.3/4” (Various ODs).
- 5.1/2” also available in heavy duty passive (5°) and spiral blade design.
- World record holder: highest step-out ratio completion. Step out ratio of 5.84:1, length of 12,172ft (3,710m), TVD of 2,090ft (636.6m).
- Self lubricating, ultralow friction – the lowest friction, solid centralizer in the industry.
- ERD and very high step-out ratio horizontal wells.
- Complex, high value, multilateral completions.
- Max operating temp: 271°F/133°C.
- Sizes: 4.1/2” to 9.5/8” (Various ODs)
Centralizadores y Resina Epoxica
![](https://oilandgassupplier.com/wp-content/uploads/2022/10/products-draco.png)
Well Constructions
Se ofrece la solución de una familia de resina epoxica, única en el mercado
nacional con mejores características de alta resistencia y compresión llamada DRACO BBC para centralización de tubería de revestimiento y DRILL BBC para uso en tubería de perforación como reductores de fricción y en conversión de zapata guía o flotadoras en zapata rimadora. Esta resina puede ser moldeada en diferentes diseños de longitud, ancho, inclinación y altura de las aletas que conforman un centralizador, con la versatilidad de diseñar específicamente de acuerdo a la configuración del pozo.
Características innovadoras:
- Resina epoxica de alta resistencia y alta compresión.
- Permite el diseño con configuración y medida personalizada.
- Beneficia a la reducción de torque y arrastre.
![](https://oilandgassupplier.com/wp-content/uploads/2022/11/drac1.jpeg)
![](https://oilandgassupplier.com/wp-content/uploads/2022/11/drac2.jpeg)
Catálogo de Productos
Revisa el catálogo con todos nuestros productos relacionados a la perforación y extracción en pozos petroleros
